Actuator: (MK-6801):|Actuator Type: Pneumatic |Control Signal: Proportional |Control Spring Range: 3 to 8 PSIG |Loss of Power Type: Spring Return |Leads and Connections: 1/8 in Air NPT |Mechanical Movement: Linear |Protection Rating: NEMA 1 |Product Line: Schneider Electric |Product Series: MK-6800 |Actuator Use: Globe Valves
- Actuator Product Series : MK-6800~~
- Actuator Type : Pneumatic
- Brand : Schneider Electric
- By Schneider : Yes
- Circularity Profile : No need of specific recycling operations
- Control Signal : Proportional/Modulating
- Control Spring Range : 3 to 8 PSIG
- Diaphragm Effective Area : 50 in² (322.6 cm²)
- Final Result for Connectable : Not connectable
- Final Result for Flywheel performance tracking : Non Flywheel
- IP Protection Rating : IP10
- Lead Length : 1/8 in
- Leads and Connections : Air NPT
- Loss of Power Type : Spring return
- Manufacturer : Schneider Electric
- Material : Die cast aluminium: housing
- Material Diaphragm : Neoprene
- Mechanical Movement : Linear
- Override : Manual override with 5/32 allen wrench
- Packaging made with recycled cardboard : Yes
- Packaging without single use plastic : No
- Position Indicator : Green Push Stem with Color Markers
- Positioner : No
- Product Destination : globe valve
- Product Or Component Type : Actuator
- Selection Tools : Valve Selection Tool
- Stroke Auto Calibration : No
- Take-back : No
- Temperature Ambient Operating Range : -20…220 °F (-28.8…104.4 °C)
- Temperature Shipping and Storage Range : -40…220 °F (-40…104.4 °C)
