SURTD5000RMXLP3U

acoustic level :

55 dBA~~

Additional Information :

Configurable for 208 or 240 nominal output voltage

After sales category ASC :

03 - Replace by the "same" Commercial Reference but Refurbished or Remanufactured

Battery Charge Power (Watts) :

382 W rated

battery curve :

C

battery design life :

2 year(s)

Battery Life :

3…5 year(s)

battery option :

SURT192RMXLBP3U 1 2880 VAh

battery option :

SURT192RMXLBP3U 10 20160 VAh

battery option :

SURT192RMXLBP3U 2 4800 VAh

battery option :

SURT192RMXLBP3U 3 6720 VAh

battery option :

SURT192RMXLBP3U 4 8640 VAh

battery option :

SURT192RMXLBP3U 5 10560 VAh

battery option :

SURT192RMXLBP3U 6 12480 VAh

battery option :

SURT192RMXLBP3U 8 16320 VAh

Battery power in VAH :

960 VAh runtime

Battery Type :

Lead-Acid battery

Brand :

APC Brand

bypass type :

Internal Bypass (Automatic and Manual)

Cable Length :

10 ft (3.05 m)

California proposition 65 :

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Carbon footprint (kg CO2 eq, Total Life cycle) :

13018

Channel status :

Distribution

Color :

Black

Configurators/Selectors :

Computer rooms

Configurators/Selectors :

NetShelter

Configurators/Selectors :

PowerStruXure Type A

Configurators/Selectors :

UPS Selector

Configurators/Selectors :

Wiring closets

CR access level :

Non-Restricted - Does not require certified representative for installation

CR severity code :

06 - Product as a spare

CR shelf life :

12

crest factor :

3 : 1

curve equation :

Efficiency

curve load maximum :

100 %

curve X-axis maximum :

100 %

curve X-axis minimum :

0 %

curve X-axis title :

Load

curve X-axis units :

Percentage

curve Y-axis maximum :

100 %

curve Y-axis minimum :

50 %

curve Y-axis title :

Efficiency

curve Y-axis units :

Percentage

Depth :

25.98 in (66 cm)

Efficiency at full load :

156...236 V

Efficiency at full load :

85...136 V adjustable

Efficiency at full load :

90 % full load)

Emergency Power Off (EPO) :

Yes

Extendable Run Time :

1

Filtering :

Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : m

Final Result for Connectable :

Connectable ready

Final Result for Flywheel performance tracking :

Connectable products

For Service Catalog Item :

Finished good

Form name :

UPS

free slots :

0

Global Keywords :

Smartup

Global Keywords :

Smartups

Global Keywords :

Ups

Global warming ; Total life cycle? :

13 018 kg CO2 eq.

graph display :

1

harmonic distortion :

Less than 2%

Heat Dissipation :

1589 Btu/h

Height :

5.12 in (13 cm)

Included Battery Modules :

2

Input Connection Type :

NEMA L14-30P

Input Frequency :

50/60 Hz +/- 5 Hz auto-sensing

IP Degree of Protection :

IP20

Kw Rating :

4000 W

Lead time :

Usually in Stock

Liquid Electrolyte Value :

0

Main Input Voltage :

208 V

Manufacturer :

American Power Conversion Corp. (APC)

Max Configurable Power (Watts) :

4000 W

Maximum configurable power in VA :

5000 VA

Mounting Location :

Front

Mounting Mode :

Rack-mounted

Mounting Preference :

Lower

Net Weight :

128.0005 lb(US) (58.06 kg)

Number Of Cables :

1

Number of power module filled slots :

0

Number of power module free slots :

0

number of rack unit :

3U

Number of tare power :

60 W

OEM :

APC

Operating Altitude :

0...10000 ft

Optimized Energy Efficiency :

Energy efficient product

Order method :

ERP to ERP

Other Input Voltages :

240 V

Other Output Voltages :

240 V

output connection type :

1 NEMA L14-30R

output connection type :

1 NEMA L6-30R

output connection type :

4 NEMA 5-20R

Output frequency :

50/60 Hz +/- 3 Hz user adjustable +/- 0.1 sync to mains

Output Voltage :

120 V

Output Voltage :

208 V

Packaging made with recycled cardboard :

Yes

Packaging without single use plastic :

No

performance multiplier :

1

Pre-Installed SmartSlotâ„¢ Cards :

Network management card 2 with environmental monitoring

Presentation :

High density, double-conversion on-line power protection with scalable runtime.

Preventive maintenance :

0

Prod Type :

UPS

Product Certifications :

CSA

Product Or Component Type :

Uninterruptible power supply (UPS)

Provided Equipment :

CD with software

Provided Equipment :

Rack Mounting support rails

Provided Equipment :

Removable support feet

Provided Equipment :

Smart UPS signalling RS-232 cable

Provided Equipment :

User Manual

Rated Power In Va :

5000 VA

RBC Quantity :

1

redundant :

No

Relative Humidity :

0…95 % non-condensing

Removable battery :

User replaceable

Return code :

01 - Return for Repair (RFR)

show note OP temperature :

No

size UPS version :

Internetworking

size UPS version :

Server

size UPS version :

Telecom

Spare Part Order Method direction :

Consult local ERP Setup

Spare used in spare kit :

No

Storage Altitude :

0…50000 ft (0…15240 m)

Storage Relative Humidity :

0…95 % Non-condensing

Surge energy rating :

365 J

Take-back :

Yes

Temperature Ambient Operating Range :

32…104 °F (0…40 °C)

Temperature Shipping and Storage Range :

5…113 °F (-15…45 °C)

Topology :

Double Conversion Online

two post mountable :

0

Typical recharge time :

2.5 h

UNSPSC Classification v19 :

39121011

UNSPSC Classification v23 :

39121011

UPS design life :

7 year(s)

UPS size :

S

USB compatible :

No

value multiplier :

1

Warranty :

2 years repair or replace

Waveform Type :

Sine wave

Width :

17.01 in (43.2 cm)

PDF :

https://iportal2.schneider-electric.com/Contents/docs/UPS-JLAI-7UD9ET_R1_EN.PDF
