APC Smart-UPS X 3000VA Rack/Tower LCD 200-240V with Network Card
- acoustic level : 55 dBA~~
- additional specification : Network card pre-installed
- After sales category ASC : 03 - Replace by the "same" Commercial Reference but Refurbished or Remanufactured
- Battery Charge Power (Watts) : 245 W rated
- battery curve : C
- Battery Life : 3…5 year(s)
- battery option : SMX120RMBP2U 1 2214 VAh
- battery option : SMX120RMBP2U 10 15498 VAh
- battery option : SMX120RMBP2U 2 3690 VAh
- battery option : SMX120RMBP2U 3 5166 VAh
- battery option : SMX120RMBP2U 4 6642 VAh
- battery option : SMX120RMBP2U 6 9594 VAh
- battery option : SMX120RMBP2U 8 12546 VAh
- Battery power in VAH : 738 VAh runtime
- Battery Slots Empty : 0
- Battery Type : Lead-Acid battery
- Brand : APC Brand
- Cable Length : 8 ft (2.4 m)
- Carbon footprint (kg CO2 eq, Total Life cycle) : 2724
- Channel status : Distribution
- Circular Eligibility : Refurbish list
- Color : Black
- Configurators/Selectors : UPS Selector
- Configurators/Selectors : UPS Selector Business Power
- Control panel : Multi-function LCD status and control console
- CR severity code : 06 - Product as a spare
- CR shelf life : 12
- curve equation : Efficiency
- curve fixed loss : 0.014
- curve load maximum : 100 %
- curve load minimum : 2 %
- curve proportional loss : 0.0003
- curve square loss : 0.0013
- curve X-axis maximum : 100 %
- curve X-axis minimum : 0 %
- curve X-axis title : Load
- curve X-axis units : Percentage
- curve Y-axis maximum : 100 %
- curve Y-axis minimum : 50 %
- curve Y-axis title : Efficiency
- curve Y-axis units : Percentage
- Depth : 26.26 in (66.7 cm)
- Efficiency at full load : 140...280 V
- Emergency Power Off (EPO) : Yes
- Extendable Run Time : 1
- Final Result for Connectable : Connectable ready
- Final Result for Flywheel performance tracking : Connectable products
- For Service Catalog Item : Finished good
- Form name : UPS
- free slots : 0
- Global Keywords : 3000VA sine wave UPS
- Global Keywords : APC Smart-UPS X
- Global Keywords : AVR UPS
- Global Keywords : Battery backup
- Global Keywords : EcoStruxure IT
- Global Keywords : Extendable runtime UPS
- Global Keywords : Network monitoring SMX UPS
- Global Keywords : Rack tower convertible 2U UPS
- Global Keywords : Schneider Electric line interactive Smart UPS
- Global Keywords : Switchable outlet group UPS
- Global Keywords : Uninterruptible power supply
- Global Keywords : Ups
- Global Keywords : User selectable high voltage UPS
- Global warming ; Total life cycle? : 2 724 kg CO2 eq.
- graph display : 1
- harmonic distortion : Less than 5%
- Heat Dissipation : 184 Btu/h
- Height : 3.35 in (8.5 cm)
- Included Battery Modules : 0
- Indivisible Sale Qty : 1
- Input Connection Type : BS1363A British
- Input Connection Type : IEC 320 C20
- Input Connection Type : Schuko CEE 7 / EU1-16P
- Input Frequency : 50/60 Hz +/- 3 Hz auto-sensing
- Kw Rating : 2700 W
- Lead time : Usually in Stock
- Liquid Electrolyte Value : 0
- Main Input Voltage : 208 V
- Main Input Voltage : 230 V
- Manufacturer : American Power Conversion Corp. (APC)
- Max Configurable Power (Watts) : 2700 W
- Maximum configurable power in VA : 3000 VA
- Mounting Location : Front
- Mounting Mode : Rack-mounted
- Mounting Preference : Lower
- Net Weight : 82.28 lb(US) (37.32 kg)
- Number Of Cables : 1
- Number of power module : 0
- Number of power module filled slots : 0
- Number of power module free slots : 0
- number of rack unit : 2U
- Number of tare power : 41 W
- Number of Units in Package 2 : 8
- OEM : APC
- Operating Altitude : 0...10000 ft
- Optimized Energy Efficiency : Energy efficient product
- Order method : ERP to ERP
- Other Input Voltages : 220 V
- Other Input Voltages : 240 V
- Other Output Voltages : 208 V
- Other Output Voltages : 220 V
- Other Output Voltages : 240 V
- output connection type : 1 IEC 320 C19
- output connection type : 2 IEC Jumpers
- output connection type : 8 IEC 320 C13
- Output frequency : 50/60 Hz +/- 3 Hz sync to mains
- Output Voltage : 230 V
- Package 2 Height : 46.85 in (119 cm)
- Package 2 Length : 47.24 in (120 cm)
- Package 2 Weight : 843.05 lb(US) (382.4 kg)
- Package 2 width : 39.37 in (100 cm)
- Packaging made with recycled cardboard : Yes
- Packaging without single use plastic : No
- Pallet layers : 4
- Pallet unit layers : 2
- performance multiplier : 1
- Pre-Installed SmartSlotâ„¢ Cards : Network management card 3 with environmental monitoring
- Preventive maintenance : 0
- Prod Type : UPS
- Product Certifications : CE
- Product Certifications : C-tick
- Product Certifications : EAC
- Product Certifications : GOST
- Product Certifications : IRAM
- Product Certifications : UK PSTI
- Product Certifications : VDE
- Product Or Component Type : Uninterruptible power supply (UPS)
- Provided Equipment : CD with software
- Provided Equipment : Rack Mounting support rails
- Provided Equipment : Smart UPS signalling RS-232 cable
- Provided Equipment : Temperature Probe
- Provided Equipment : User Manual
- Provided Equipment : Web/SNMP Management Card
- Rated Power In Va : 3000 VA
- RBC Quantity : 1
- redundant : No
- Relative Humidity : 0…95 %
- Removable battery : User replaceable
- Return code : 01 - Return for Repair (RFR)
- SCIP Number : 5ee38369-4dfb-4636-ab65-b08aa3242891
- show note OP temperature : No
- size UPS version : Internetworking
- size UPS version : Server
- size UPS version : Telecom
- Spare Part Order Method direction : Consult local ERP Setup
- Spare used in spare kit : No
- Standards : EN/IEC 62040-1:2019/A11:2021
- Standards : EN/IEC 62040-2:2006/AC:2006
- Standards : EN/IEC 62040-2:2018
- Storage Altitude : 0…50000 ft (0…15240 m)
- Storage Relative Humidity : 0…95 %
- Surge energy rating : 645 J
- Take-back : Yes
- Temperature Ambient Operating Range : 32…104 °F (0…40 °C)
- Temperature Shipping and Storage Range : 5…113 °F (-15…45 °C)
- Topology : Line Interactive
- Transfer Time : 2-4 ms
- Transfer Time : 6ms typical : 10ms maximum
- two post mountable : 0
- Typical recharge time : 3 h
- Unit Type of Package 2 : PAL
- UNSPSC Classification v19 : 39121011
- UNSPSC Classification v23 : 39121011
- UPS size : S
- USB compatible : Yes
- value multiplier : 1
- Volume of Package 2 : 1428000 cm3
- Waveform Type : Sine wave
- Width : 17.01 in (43.2 cm)
