TCI NEMA 1 ENCLOSURE
- Lead time : Usually in Stock
- Main Input Voltage : 120 V
- Input Connection Type : NEMA 5-15P
- Cable length : 2 ft (0.61 m)
- Number of cables : 1
- Provided equipment : Detachable power cord, User Manual, Wall-mounting template
- Color : Black
- Height : 3.70 in (9.4 cm)
- Width : 6.69 in (17 cm)
- Depth : 1.61 in (4.1 cm)
- Net Weight : 1.50 lb(US) (0.68 kg)
- Mounting preference : No preference
- Mounting Mode : Not rack-mountable
- Input Frequency : 50/60 Hz
- Switching current capacity : 15 A
- Maximum Input Current per Phase : 12 A
- Number of power socket outlets : 2
- Outlet standard : NEMA 5-15R
- Product Certifications : cUL Listed, NOM
- Standards : FCC part 68, UL 1363, UL 1449
- Equipment protection policy : Lifetime : $350000
- UL 1449 TVSS Rating : 400
- Ambient Air Temperature for Operation : 32…122 °F (0…50 °C)
- Operating altitude : 0...10000 ft
- Relative Humidity : 0…95 %
- Ambient Air Temperature for Storage : 5…113 °F (-15…45 °C)
- Storage altitude : 0…50000 ft (0.00…15240.00 m)
- Storage Relative Humidity : 0…95 %
- Let Through Voltage Rating : 40 V
- NM Surge Response Time (ns) : 0 ns common mode
- Common mode rejection : 55 dB
- Surge energy rating : 1890 J
- Category : 11309-APC RESALE PRODUCTS
- Discount Schedule : APC1
- GTIN : 731304248842
- Returnability : No
- Country of origin : PH
- Unit Type of Package 1 : PCE
- Number of Units in Package 1 : 1
- Package 1 Height : 10.00 in (25.4 cm)
- Package 1 Width : 1.50 in (3.8 cm)
- Package 1 Length : 7.99 in (20.3 cm)
- Package 1 Weight : 1.98 lb(US) (0.9 kg)
- SCC14 : 10731304248849
- Warranty : Lifetime
