- [Ue] rated operational voltage : 125...300 V DC
- [Ue] rated operational voltage : 156...600 V AC 50/60 Hz between phases UL
- [Ue] rated operational voltage : 90...300 V AC 50/60 Hz between phase and neutral CE
- [Ue] rated operational voltage : 90...347 V AC 50/60 Hz between phase and neutral UL
- 9 mm pitches : 12
- Accuracy Class : Class 0.2S energy ANSI C12.20
- Accuracy Class : Class 0.2S energy IEC 62053-22
- Accuracy Class : Class 0.2S power ANSI C12.20
- Accuracy Class : Class 0.2S power IEC 62053-22
- Ambient Air Temperature For Operation : -22…158 °F (-30…70 °C)
- Analogue Input Type : Low voltage current transformer 0.333 V or 1 V
- Application : Partial meter
- Application : Sub billing
- Brand : Schneider Electric
- buffer size : 32-bit 3
- By Schneider : Yes
- Color : Dark grey
- Communication Port Protocol : BACnet MS/TP 9600 bauds...115200 bauds (automatic detection) - 2-wire
- Communication Port Support : Screw terminal block RS485
- Communication Service : Total cumulated active energy
- Communication Service : Total cumulated energy
- Data Recording : Energy consumption logs
- Depth : 2.3 in (59 mm)
- Device Short Name : EM3560
- Display Digits : 5
- Display Type : Backlit LCD
- Final Result for Connectable : Connectable ready
- Final Result for Flywheel performance tracking : Connectable products
- Function Available : External synchronisation to communication
- Function Available : Fixed or rolling block
- Global Keywords : Class 0.2S
- Global Keywords : EM3500
- Global Keywords : Energy meter
- Global Keywords : Low voltage current transducer
- Global Keywords : LVCT
- Global Keywords : PowerLogic
- Global Keywords : PowerLogic EM3500
- Global Keywords : Pulse
- Height : 3.6 in (91 mm)
- Indivisible Sale Qty : 1
- Information Displayed : Communication with system
- Information Displayed : Error
- Information Displayed : Input/output status
- Information Displayed : Instant power per usage
- Information Displayed : Rx activity
- Information Displayed : Status and alert
- Information Displayed : Tx activity
- Local Signalling : Green flashing LED output signal
- Local Signalling : Red LED threshold reached
- Measurement Accuracy : Energy +/- 0.2 %
- Measurement Accuracy : Power +/- 0.2 %
- Measurement Current : 5…32000 A
- Metering Type : Current I1, I2, I3, Iavg
- Metering Type : Demand power P, Q, S
- Metering Type : Peak demand power PM, QM, SM
- Metering Type : Voltage U21, U32, U13, V1, V2, V3
- Mounting Mode : By screws
- Mounting Mode : Clip-on
- Mounting Support : DIN rail
- Network Frequency : 50 Hz
- Network Frequency : 60 Hz
- Number Of Inputs : 1 pulse
- Number Of Outputs : 1 alarm output
- Packaging made with recycled cardboard : No
- Packaging without single use plastic : No
- Power Consumption In Va : 5 VA 347 V AC between phase and neutral)
- Power Consumption In Va : 5 VA 600 V AC between phases)
- Power Consumption in W : 3 W 300 V
- Product Certifications : CE conforming to IEC 61010
- Product Certifications : CULus conforming to UL 508
- Product Name : PowerLogic EM3500
- Product Or Component Type : Energy meter
- Range : PowerLogic
- Rated Voltage : 90…347 V
- Relative Humidity : 0…95 %
- Ride-Through Time : 100 ms 120 V AC
- Standards : CSA C22.2 No 14-05
- Standards : IEC 61010-1
- Standards : UL 508
- Take-back : No
- Tamperproof Of Settings : Protected by access code
- Technology Type : Electronic
- Temperature Shipping and Storage Range : -40…185 °F (-40…85 °C)
- Type Of Measurement : Active and reactive power per phase
- Type Of Measurement : Active and reactive power total
- Type Of Measurement : Apparent power per phase
- Type Of Measurement : Apparent power total
- Type Of Measurement : Current
- Type Of Measurement : Frequency
- Type Of Measurement : Peak demand power
- Type Of Measurement : Power factor per phase
- Type Of Measurement : Power factor total
- Type Of Measurement : Voltage
- Type Of Network : 3P + N
- UNSPSC Classification v19 : 39121032
- UNSPSC Classification v23 : 39121032
- Width : 4.2 in (107 mm)~~
