Square D™ load center surge protective devices, TVS4IMA16O, are easy to install plug-in units that install as quickly as a standard circuit breaker. The surge suppressors use two pole spaces in a QO™ or Homeline™ load center, or NQ panelboard. US and Canadian UL® Listed as Type 2 SPD to the UL 1449 standard. Complies with requirements of NEC® Article 285, CSA 233.1-87, and CSA C22.2 No. 8- M1986 as appropriate.
- Product : Surge protection device
- Range : Surgelogic
- Device Short Name : IMA
- Voltage Rating : 277Y/480 V AC
- MCOV : 320 V
- SCCR : 200 kA
- Surge Current : 160 kA per phase
- Nominal Discharge Current : 20 kA
- Number of Phases : 3 phase
- Wiring Configuration : 4-wire
- Provided Equipment : Alarm enable/disable switch, Diagnostic display, Backplane, Cables
- Height : 6.13 in (155.7 mm)
- Width : 9.86 in (250.4 mm)
- Depth : 3.65 in (92.7 mm)
- Enclosure Rating : NEMA 2
- Category : US1DE1B08468
- Discount Schedule : DE1B
- GTIN : 785901600749
- Returnability : Yes
- Country of origin : MX
- Unit Type of Package 1 : PCE
- Number of Units in Package 1 : 1
- Package 1 Height : 7.50 in (19.05 cm)
- Package 1 Width : 9.40 in (23.876 cm)
- Package 1 Length : 12.30 in (31.242 cm)
- Package 1 Weight : 8.40 lb(US) (3.81 kg)
- Warranty : 18 months
