Schneider Electric offers transformers with internally pre-wired 24-inch primary and secondary leads, instead of terminal boards, to make installation easier and faster for many applications. These are only available for single voltage primary and single voltage secondary applications. This Industrial Control transformer, is 1 phase, with a rated voltage of 50 VA. This transformer, has primary voltages of 480/440/460 V and secondary voltages of 115/120/110 V. This product has a temperature rise of 55 °C and a insulated temperautre of 105 °C. This product complys to UL listed,CSA & CE standards. This product comes with a 610 m lead and has screw clamp terminals connections.
- Product or Component Type : Industrial Control Transformer
- Range of Product : EL
- Phase : 1 phase
- Rated power in VA : 50 VA
- Primary Voltage : 480 V, 440 V, 460 V
- Secondary Voltage : 115 V, 120 V, 110 V
- Temperature rise : 55 °C
- Electrical Connection : Screw clamp terminals
- Connector type : Lead 2001.31 ft (610 m)
- Product Certifications : UL Listed, CSA, CE
- NEMA Degree of Protection : Not rated (open device)
- Insulation temperature : 221 °F (105 °C)
- Category : US10CP821691
- Discount Schedule : 0CP8
- GTIN : 785901020219
- Returnability : Yes
- Country of origin : MX
- Unit Type of Package 1 : PCE
- Number of Units in Package 1 : 1
- Package 1 Height : 3.70 in (9.398 cm)
- Package 1 Width : 4.00 in (10.16 cm)
- Package 1 Length : 4.10 in (10.414 cm)
- Package 1 Weight : 2.61 lb(US) (1.184 kg)
- Warranty : 18 months
