Linear actuator, 50 N, AC/DC 24 V, On/Off, Floating point, 122 s, Stroke 60 mm, IP20
- Voltage AC/DC : AC/DC 24 V
- Power Consumption (Running) : 1 W
- Power Consumption (Holding) : 0.5 W
- Power Consumption For Wire Sizing : 2 VA
- Connection Supply Control : Connector Plug (Cable-side connector socket not included in scope of delivery)
- Connection Plug : Molex Mini-Fit Jr. 39303035
- Force : 50 N
- Control Type : On/Off ; Floating/3-point
- Direction Of Motion Motor : by electrical installation
- Manual Override : No
- Stroke : 60 mm
- Running Time (Motor) : 122 s / 100 mm
- Protection category : IP20
- Degree Of Protection NEMA : NEMA 1
- Enclosure Type : UL Enclosure Type 1
- Ambient Tempreture : -22...122°F [-30...50°C]
