This selector switch is part of the range of control and signaling units, Harmony 9001K diameter 30mm metal. It has a chromium-plated metal bezel. It is supplied without knob. It is easily installed into a standard 30mm diameter panel cut-outs. It features 2 positions operator and is supplied without contacts. The 30 mm Harmony range offers a large choice of robust and reliable products to meet a great number of applications in heavy industries such as petrochemy, metallurgy, mining oil and gas wastewater treatment, automobile manufacturing. It is UL listed and CSA certified, CE declaration of conformity and RoHS compliant.
- Range of Product : Harmony 9001K
- Product or Component Type : Head for selector switch
- Device short name : K
- Type of operator : maintained
- Operator profile : Without cap without knob
- bezel material : Metal
- Mounting diameter : 1.18 in (30 mm)
- Operator position information : 2 positions
- Contacts type and composition : Without contact block
- device presentation : Basic element
- Operator profile : Without handle
- Type of operator : Stay put
- Size : 30 mm
- Cam profile : 5
- NEMA degree of protection : NEMA 1/2/3/3R/4/6/12/13
- Product Certifications : CSA LR24590 class 3211 03, CE, UL listed file E42259 CCN NKCR
- Category : US10CS121426
- Discount Schedule : 0CS1
- GTIN : 785901322825
- Returnability : Yes
- Country of origin : MX
- Unit Type of Package 1 : PCE
- Number of Units in Package 1 : 1
- Package 1 Height : 2.80 in (7.112 cm)
- Package 1 Width : 2.30 in (5.842 cm)
- Package 1 Length : 2.10 in (5.334 cm)
- Package 1 Weight : 4.32 oz (122.47 g)
- Warranty : 18 months
