C7170 immersion sensors are intended for monitoring or controlling temperature in conjunction with an electronic control. They are the primary electronic temperature sensors for the R7380J,L, W7100 and W7505 load inputs for immersion, strap-on, and duct"|Room Sensor: Wall mount: Used with EXCEL 500
- Dimensions (in.) : 2 13/16 in. high x 4 5/8 in. wide
- Dimensions (mm) : 71.4mm high x 118 mm wide
- Used With : Excel 500, T775 Series 2000
- Item Type : Product
- Mounting : Wall mount
- Sensor : PT1000, 1097 ohms @ 77 F PTC
- Operating Temperature Range (F) : -40 F to +100 F
- Operating Temperature Range (C) : -40 C to +38 C
- Shipping and Storage Temperature Range (F) : -40 F to +150 F
- Shipping and Storage Temperature Range (C) : -40 C to +65 C
- Ambient Temperature Range (F) : 150 F Maximum
- Ambient Temperature Range (C) : 66 C Maximum
- Cable Length : 300foot; 91metre
- For Use With : T775 Series 2000volt; Excel 500volt
- Maximum Operating Ambient Temperature : 38degree Celsius; 100degree Fahrenheit
- Sensor Functions : Temperature; 1097 Ω @ 77 (25 °C)degree Fahrenheit
- Mounting Type : Wall
- Overall Width : 4-5/8inch; 118millimetre
- Overall Height : inch
- SKU Type : Electric
- Maximum Shipping & Storage Temperature : 65degree Celsius; 150degree Fahrenheit
- Minimum Operating Ambient Temperature : -40degree Fahrenheit; -40degree Celsius
- Temperature Sensor Output : 1097 ohm at 77F (25C)
- Minimum Shipping & Storage Temperature : 40degree Celsius; -40degree Fahrenheit
- Minimum Operating Ambient Temperature : -40degree Celsius; -40degree Fahrenheit
