Volumetric flow controller VAV-Compact 6" [DN 150], 2 Nm, AC/DC 24 V, On/Off, Floating point, 58 s, IP54
- Voltage AC/DC : AC/DC 24 V
- Power Consumption (Running) : 0.5 W
- Power Consumption (Holding) : 0.2 W
- Power Consumption For Wire Sizing : 1 VA
- Torque : 2 Nm
- Control Type : On/Off ; Floating/3-point
- Manual Override : Disengage with magnet
- Angle of Rotation : 70
- Running Time (Motor) : 58 s / 70°
- Protection category : IP54
- Degree Of Protection NEMA : NEMA 2
- Enclosure Type : UL Enclosure Type 2
- Ambient Tempreture : -22...122°F [-30...50°C]
