Linergy NSYTR plug-in bridge for terminal block. It has red surface treatment. It provides 10 ways for 4mm² terminals. It is compatible with TRV screw terminal, TRH IDC, TRP push-in and TRR spring terminal block. Sold in lots of 10 units. It is compliant with Green Premium (RoHS/REACH).
- Range : Linergy
- Product name : Linergy TR
- Product or Component Type : Plug-in bridge
- Device short name : TRA
- Accessory / separate part category : Connection accessory
- Number of ways : 10 ways
- Cable cross section : 0.01 in² (4 mm²)
- number of connections : 2, 4, 3
- Number of measurement input : 2, 6, 1, 4, 3
- Quantity per Set : Set of 10
- Net Weight : 0.36 oz (10.1 g)
- color : Red
- Category : US10CP521715
- Discount Schedule : 0CP5
- GTIN : 3606480534171
- Returnability : Yes
- Country of origin : DE
- Unit Type of Package 1 : PCE
- Number of Units in Package 1 : 1
- Package 1 Height : 0.12 in (0.3 cm)
- Package 1 Width : 0.98 in (2.5 cm)
- Package 1 Length : 2.36 in (6.0 cm)
- Package 1 Weight : 0.32 oz (9.0 g)
- Unit Type of Package 2 : BB1
- Number of Units in Package 2 : 10
- Package 2 Height : 1.18 in (3.0 cm)
- Package 2 Width : 2.17 in (5.5 cm)
- Package 2 Length : 2.76 in (7.0 cm)
- Package 2 Weight : 3.50 oz (99.1 g)
- Unit Type of Package 3 : S03
- Number of Units in Package 3 : 1000
- Package 3 Height : 11.81 in (30.0 cm)
- Package 3 Width : 11.81 in (30.0 cm)
- Package 3 Length : 15.75 in (40.0 cm)
- Package 3 Weight : 22.90 lb(US) (10.388 kg)
- Warranty : 18 months
