SAV61.00U - PICV Actuator, 24 Vac, 0-10 Vdc or 4-20 mA Prop Control, Non-Spring Return
Technical Specifications:
- Spring return function: No
- Position feedback: DC 0…10 V
- Power consumption: 9.5 VA
- Mounting position: Upright to horizontal, up to 150 °C with horizontal mounting position
- Ambient humidity, operation: 95 % r.h.
- Operating voltage: 19.2…28.8 V24 V#AC/DC
- Stroke: 40 mm, 1.5 "" mm
- Positioning time: 120 s
- Stroke, mm: 40 mm
- Auxiliary switch: Optional
- Ambient temperature, operation: -5…55 °C
- Degree of protection: IP54
Product Literature:
Brand: Siemens
SKU: SAV61.00U
