Schneider Electric KEL-FB3 1/2IN NPT TO 1/8IN NPS ADAPTER

Model WEL-B and WEL-S Sensor Wells are used with standard length Kele and Precon branded immersion thermistor and RTD sensors. These wells may be used with 5 in. (12.7 cm) Minco immersion sensors by using the H option adapter. The well is designed to be installed into a standard 1/2 in. saddle or Thredolet. The WEL-B Brass Thermowell is the standard thermowell for inserting into noncorrosive liquid lines. It will withstand a maximum temperature of 400 deg. F (204 deg. C) and a maximum static pressure of 1000 psig (6.9 MPa).The WEL-S 304 Stainless Steel Thermowell is inserted into corrosive liquid pipe lines. It will withstand a maximum temperature of 1000 deg. F (538 deg. C) and a maximum static pressure of 4500 psig (31 MPa). The F2S-D Stainless Steel, F2N-D Nylon, or the F2B-D Brass Well Adapter allows a 1/4 in. (0.64 cm) diameter sensor probe with a 1/2 in. NTSM fitting to be used with a standard WEL-B or WEL-S Thermowell. WARRANTY 1 year
