Discrete Input Module + Base, 6 In, 24V DC, Sink, 1/2/3 Wires, Modicon Edge I/O NTS
- Ambient Air Temperature For Operation : -4…140 °F (-20…60 °C)~~
- Ambient Air Temperature For Storage : -40…185 °F (-40…85 °C)
- Application : Industrial Application
- Brand : Schneider Electric
- By Schneider : Yes
- Carbon footprint (kg CO2 eq, Total Life cycle) : 23
- Color Casing : Grey
- Current State 1 Guaranteed : >= 2 mA
- Depth : 3.1 in (80 mm)
- Directives : 2014/30/EU - electromagnetic compatibility
- Directives : 2014/34/EU - ATEX directive
- Directives : 2014/35/EU
- Discrete Input Current : 2.5 mA
- Discrete Input Logic : Positive logic (sink)
- Discrete Input Number : 6
- Discrete Input Number : 6 type 3 conforming to IEC 61131-2
- Discrete Input Voltage : 24 V DC
- Final Result for Connectable : Connectable ready
- Final Result for Flywheel performance tracking : Edge control
- Global Keywords : Device Genuineness
- Global Keywords : Digital Input Module
- Global Keywords : Discrete input module
- Global Keywords : Edge I/O NTS
- Global Keywords : Hotswap
- Global Keywords : Hot-swap
- Global Keywords : Hot-swappable
- Global warming ; Total life cycle? : 23 kg CO2 eq.
- Group of input channels : 1 group
- Height : 3.9 in (100 mm)
- hot swapping fallback : Yes
- Indivisible Sale Qty : 1
- Input diagnostic : Power supply error per channel
- Input diagnostic : Sensor power supply error per channel
- input filtering : 0...20 ms configurable in 0.1 ms step
- Input Impedance : 9.6 kOhm
- input protection type : Over current protection on sensor supply
- input protection type : Over voltage protection
- input protection type : Reverse polarity protection
- Input wiring mode : 1, 2 or 3 wires
- IP Degree of Protection : IP20
- Isolation Between Channels And Bus : 1500 V AC
- isolation between channels and ground : 1500 V AC
- Kit Composition : NTSDDI0602 module
- Kit Composition : NTSXBA0100H base
- Local Signalling : 1 LED (green) for module operating (RUN)
- Local Signalling : 1 LED (red) for module error (ERR)
- Local Signalling : 1 LED per channel (green) for channel diagnostic
- Mandatory accessory : NTSXTB18_0_H terminal block
- Manufacturer : Schneider Electric
- Marking : CE
- Marking : CULus
- Marking : RCM
- Marking : UKCA
- Mounting Support : Top hat type TH35-15 IEC 60715
- Mounting Support : Top hat type TH35-7.5 IEC 60715
- Net Weight : 0.161 lb(US) (0.073 kg)
- Number of Units in Package 2 : 16
- Operating Altitude : 0...6561.68 ft (0...2000 m) without derating
- Operating Altitude : 2000...5000 m with derating
- Operating Mode : Synchronous/Isochronous
- Package 2 GTIN : 13606486877590
- Package 2 Height : 5.91 in (15.000 cm)
- Package 2 Length : 15.75 in (40.000 cm)
- Package 2 Weight : 4.134 lb(US) (1.875 kg)
- Package 2 width : 5.91 in (15.000 cm)
- Packaging made with recycled cardboard : No
- Packaging without single use plastic : No
- paralleling of inputs : Yes
- Pollution Degree : 2
- power dissipation in W : 1.24 W maximum at 24 V DC
- power supply type : Bus power from power supply bus (24 Vdc)
- power supply type : Field power from power supply field (24 Vdc)
- power supply type : Optional field power from common distribution module (24 Vdc)
- power supply type : Optional field power from external power supply (24 Vdc, shared 0 V with module)
- Product Certifications : ATEX Zone 2 (pending)
- Product Certifications : CCC Ex zone 2 (pending)
- Product Certifications : CE
- Product Certifications : CULus
- Product Certifications : EAC (pending)
- Product Certifications : IECEx zone 2 (pending)
- Product Certifications : Merchant Navy - EU RO MR (pending)
- Product Certifications : RCM
- Product Certifications : UKCA
- Product Compatibility : NTSN.....
- Product Or Component Type : Discrete input module kit
- Range Compatibility : Logic/motion controller - Modicon M262
- Range Compatibility : Modicon M580
- Range Compatibility : Third party
- rated operational voltage limits : 20.4...28.8 V DC
- Relative Humidity : 5…95 % without condensation
- Sales Unit : PCE
- shock resistance : 15 g 11 ms with and without accessory)
- Standards : EN 50121-4
- Standards : EN 50121-5
- Standards : EN 50155
- Standards : EN 61010-2-201
- Standards : EN/IEC 60079-0
- Standards : EN/IEC 61000-6-5, interface type 1 and type 2
- Standards : EN/IEC 61131-2
- Standards : EN/IEC 61850-3, location G
- Standards : IACS E10
- Standards : UL 61010-2-201
- Take-back : No
- typical current consumption : 31.2 mA 24 V DC on the Bus current
- typical current consumption : 510.1 mA 24 V DC on the internal field current maximum
- typical current consumption : 8.4 mA 24 V DC on the internal field current minimum
- Unit Type of Package 2 : S01
- vibration resistance : 1 g without accessory
- vibration resistance : 2 g with accessory
- Voltage State 1 Guaranteed : 11...30 V DC
- Volume of Package 2 : 9000.000 cm3
- Width : 0.6 in (15 mm)~~
