2510M manual motor starters are designed for manual On Off control for small motors. This three pole starter is rated for 7.5 HP at 230 VAC and 10 HP at 480 VAC three phase motors. This starter is NEMA M-1 rated. The proper thermal unit must be selected and ordered separately to provide proper overload protection for the motor. 2510M manual starters can be ordered in a variety of enclosure types. This device is in a surface mount NEMA 12 dust tight and drip tight enclosure. Enclosure as a provision to allow padlocking of this device. 2510M manual starters are UL listed and CSA certified. A NEMA 12 dusttight and driptight industrial use enclosure is used to protect this integral horsepower manual starter. This is a painted sheet steel enclosure. Enclosure is 10.92 inches tall, 5.78 inches wide and 5.76 inches deep. 2510M integral horsepower starters are UL listed and CSA certified.
- Product : Manual Starter
- Type : M
- NEMA Size : M-1
- Control Unit : Push-button
- Pilot Light : No indicator
- Horsepower Rating : 7.5 hp 200...230 V AC, 3 phase, 10 hp 380...575 V AC, 3 phase
- Voltage Rating : 600 V AC
- Number of Poles : 3P
- Starter Type : Non reversing
- Electrical Connection : Pressure wire clamp
- Overload Relay Type : Melting alloy
- Number of Thermal Units Required : 3
- Wire Gauge : AWG 14...AWG 8 copper
- Auxiliary Contacts : Without
- Height : 10.92 in (277.37 mm)
- Width : 5.78 in (146.81 mm)
- Depth : 5.76 in (146.30 mm)
- Certifications : UL listed file E42243 CCN NLRV, CSA LR60905 class 3211 05
- NEMA Enclosure Rating : NEMA 12 painted sheet steel
- Category : US10CP121103
- Discount Schedule : 0CP1
- GTIN : 785901845317
- Returnability : Yes
- Country of origin : MX
- Unit Type of Package 1 : PCE
- Number of Units in Package 1 : 1
- Package 1 Height : 6.10 in (15.5 cm)
- Package 1 Width : 6.81 in (17.3 cm)
- Package 1 Length : 11.42 in (29.0 cm)
- Package 1 Weight : 6.99 lb(US) (3.17 kg)
- Warranty : 18 months
