3-wire Differential Pressure Transducer, Wet Media, 0-100 psig, No Display SPECIFICATIONS: Input Power 12 to 30VDC/24VAC nominal, Output 3-wire transmitter; user selectable 4-20mA, (clipped and capped)/0-5V/0-10V†, Accuracy @ 25º ±1% F.S. Combined linearity, hysteresis, and repeatability; Range D accuracy ±2% F.S.**, Surge Damping Electronic; 5-second averaging, Test Mode Overrides output to full-scale (20mA, 5V, 10V), 0-100 psi (0-6.89 bar) 0-10/20/50/100psid (0-0.69/1.38/3.45/6.89 bar), Product Operating Environment -10° to 55°C (-4° to 130°F); 0 to 90%RH, non-condensing, Long Term Stability ±0.25% per year, Zero Adjust Pushbutton auto-zero and digital input (2-pos terminal block), Status Indication Dual-color LED: Green = Normal, Green Blinking = L0w > High, Red = Overrange, Red Blinking = Overpressure, Housing Material White powder-coated aluminum, Media Compatibility media compatible with 17-4 PH stainless steel, Proof Pressure Max. 2x F.S. range, Burst Pressure Max. 5x F.S. range, Temperature Compensated Range 0° to 50°C (32° to 122°F); TC Zero (
- [Us] rated supply voltage : 15...30 V DC~~
- [Us] rated supply voltage : 24 V AC
- Analogue Output Type : 0...10 V DC
- Analogue Output Type : 0...5 V DC
- Analogue Output Type : 4...20 mA
- Application : Chiller Differential Pressure Monitoring
- Application : Pump and Compressor Differential Pressure
- Brand : Veris Industries
- Burst Pressure : 500 psig (34 bar)
- By Schneider : Yes
- Controlled Fluid : Water
- Depth : 2.2 in (56 mm)
- Final Result for Connectable : Connectable ready
- Final Result for Flywheel performance tracking : Connectable products
- Fitting Size : 1/8" NPT
- Fitting Type : Female
- Global Keywords : Differential Air Pressure Transmitter
- Height : 4.02 in (102 mm)
- Humidity Calibration Certificate : None
- IP Degree of Protection : IP65
- Local Signalling : Red/green LED
- Location : Plant Room
- Manufacturer : Schneider Electric
- Material : Powder coated aluminium: enclosure
- Material : Stainless steel: Fitting
- Max Current Draw : 125 mA DC
- Max Current Draw : 280 mA AC
- Mounting Support : Panel
- Output Type : Analog
- Packaging made with recycled cardboard : No
- Packaging without single use plastic : No
- Pressure Measurement Accuracy : Range A/B: +/- 1 % FS, range C: +/- 1.5 % FS, range D: +/- 2 % FS
- Pressure Measurement Range : 0...10 psi (0...0.7 bar)
- Pressure Measurement Range : 0...100 psi (0...7 bar)
- Pressure Measurement Range : 0...20 psi (0...1.4 bar)
- Pressure Measurement Range : 0...50 psi (0...3.5 bar)
- Product Certifications : CE
- Product Or Component Type : Sensor
- Relative Humidity : 0…90 % RH, non-condensing
- Sensor Model : PWXX04S
- Standards : EN 61000-6-1
- Take-back : No
- Temperature Ambient Operating Range : 14…122 °F (-10…50 °C)
- Type Of Measurement : Differential Pressure
- Width : 5.8 in (147 mm)
- Wiring Technique : 3-wire
