547-311A - Siemens Room Condition Monitor (RCM), P1, +/- 0.05" WC (12.5 Pa), 0.50% Full Scale
- Connection cable : Removable terminal block
- Operating voltage : 18 to 32 Vac
- Communication : P1
- Display : LCD: 4.3" TFT, 480 ?272, dimmable
- Material, housing : Fire retardant plastic UL94 V-0
- Ambient temperature, operation : 32 to 120 °F, 0 to 50 °C
- Ambient humidity, operation : 5 to 95% rh (non-condensing)
- Mounting position : Mounts to triple gang, double-deep electrical box
- Pressure connection : Barbed fittings for 1/4" tubing
- Measuring range : +/- 0.05" WC, 12.5 Pa
- Measurement accuracy : 0.50% Full Scale
- Dimensions (W x H x D) : 7.45 W ?5.84 H ?0.38 D in
