599-06610

$1,339.49
(No reviews yet) Write a Review
SKU:
599-06610
Adding to cart… The item has been added
599-06610 - Flowrite two-way 2 1/2 inch high close-off valve. ANSI 125, NO, SS trim.
Valve Body Style :
Stroke-Globe
Port Configuration :
2-Way Normally open
End Connection :
Flanged
Connecting thread :
Universal bonnet for direct-coupled actuators
Material, valve body :
Cast iron ASTM A126 Class B
Material, inside set :
Body Trim: Stainless Steel , Stem: Stainless steel ASTM A582 Type 303 , Plug: Stainless Steel , Seat: Metal-to-metal , Normal Duty Packing: EPDM O-ring
Medium :
Water , Water with anti-freeze
DN :
65
Leakage rate :
ANSI Leakage Class IV
Leakage rate, class :
ANSI Leakage Class IV
Rangeability :
100:1
Medium temperature :
20…250 ºF
Stroke :
20 mm, 0.75 " mm
Stroke, mm :
20 mm
Dimensions (W x H x D) :
10.87 x 14.45 x 7.01 in
Datasheet :
https://hit.sbt.siemens.com/RWD/Binary/GetStream?VALUE=Assets%5cA6V10254823_Flowrite%2520High%2520Pressure%2520Close%2520off%2520Valves%25202-1_2%2520to%25206_en.pdf&EXT=.pdf&SID=A6V10254823&KEY=3&DTP=Data+Sheet+for+Product
Datasheet :
https://hit.sbt.siemens.com/RWD/Binary/GetStream?VALUE=Assets%5cA6V10254834_Flowrite%2520599%2520Series%2520High%2520Pressure%2520Close-Off%25202-Way%2520_en.pdf&EXT=.pdf&SID=A6V10254834&KEY=3&DTP=Data+Sheet+for+Product
Datasheet :
https://hit.sbt.siemens.com/RWD/Binary/GetStream?VALUE=Assets%5cA6V10305613_Cast%2520Iron%2520Flange%2520Dimensions%2520for%25202-1_2%2520through%25206-in_en.pdf&EXT=.pdf&SID=A6V10305613&KEY=3&DTP=Data+Sheet+for+Product
Datasheet :
https://hit.sbt.siemens.com/RWD/Binary/GetStream?VALUE=Assets%5cA6V10305771_Flowrite%25202-1_2%2520to%25206-Inch%2520Valves%2520Two-Way%2520and%2520Three_en.pdf&EXT=.pdf&SID=A6V10305771&KEY=3&DTP=Data+Sheet+for+Product
