• Open Architecture: High performance, reliableplatform enables use of hardware with MercuryOEM partners’ software solutions• Enhanced Security: Embedded crypto memorychip and data at rest encryption provides securedlayer of protection of sensitive data• OSDP Protocol: Secure channel communicationsfor reader connectivity• Versatile Interoperability: Same reliable interfaceand identical footprint as the EP controllers,enabling seamless upgrades for existingdeployments
- Application : Access control
- Application : Security
- Brand : Schneider Electric
- By Schneider : Yes
- Communication Port Support : RS485
- Current Consumption : 500 mA at 12...24 V DC (+/- 10 %)
- Depth : 1.0 in (25 mm)
- Encryption Protocol : AES 128
- Encryption Protocol : AES 256
- Encryption Protocol : TLS 1.1
- Encryption Protocol : TLS 1.2
- Final Result for Connectable : Not connectable
- Final Result for Flywheel performance tracking : Edge control
- Height : 6.0 in (152.4 mm)
- Indivisible Sale Qty : 1
- Memory Type : flash
- Number Of Inputs : 2 unsupervised input dedicated for cabinet tamper and UPS fault monitoring
- Number Of Inputs : 8 unsupervised/supervised end of line resistors standard
- Number Of Outputs : 4 form C relay output
- Output Voltage : 28 V DC,5 A for relay normally open
- Output Voltage : 30 V DC,3 A for Relay Normally Closed
- Packaging made with recycled cardboard : No
- Packaging without single use plastic : No
- Product Certifications : CE
- Product Certifications : RoHS
- Relative Humidity : 5…95 % RH, non-condensing
- Standards : FCC Part 15 class A
- Standards : NIST certified encryption
- Standards : UL 294
- Take-back : No
- Temperature Ambient Operating Range : 32…158 °F (0…70 °C)
- Temperature Shipping and Storage Range : -67…185 °F (-55…85 °C)
- Width : 1.0 in (25 mm)
