Actuator: (MP-381): |Actuator Type: Electric |Control Signal: Proportional |Control Signal Range: 2 to 12 VDC |Loss of Power Type: Non-Spring Return |Power Input Voltage: 24 VAC |Leads and Connections: Terminal Block |Torque: 220 in-lb |Mechanical Movement: Rotary |Auxiliary Switch: 1 SPDT |Additional Features: Actuator drive, Feedback potentiometer |Protection Rating: NEMA 1 |Product Line: Schneider Electric |Product Range: Gear Train |Product Series: MPx-3xx |Actuator Use: Dampers, Globe Valves
- [Us] rated supply voltage : 24 V AC~~
- Actuator Product Range : Gear Train
- Actuator Product Series : MPx-3xx
- Actuator Type : Electric
- Additional Features : Actuator Drive
- Additional Features : Feedback Potentiometer
- analogue input range : 2...12 V DC
- Auxiliary Switch : 1 SPDT
- Brand : Schneider Electric
- By Schneider : Yes
- Conduit Connection : 1/2 in
- Control Signal : Proportional/Modulating
- Final Result for Connectable : Connectable ready
- Final Result for Flywheel performance tracking : Connectable products
- Humidity : 5…95 % non-condensing
- Input Current : 2.2 A
- Insulation Class : Class II
- IP Protection Rating : IP10
- Leads and Connections : Terminal Block
- Loss of Power Type : Non-Spring Return
- Manufacturer : Schneider Electric
- Material : Die cast aluminium: housing
- Mechanical Movement : Rotary
- Motor Type : Oil immersed motor
- Override : Manual override with 5/32 allen wrench
- Packaging made with recycled cardboard : Yes
- Packaging without single use plastic : No
- Position Indicator : Green Push Stem with Color Markers
- Product Destination : dampers
- Product Destination : globe valve
- Product Or Component Type : Actuator
- Rotation : 180 °
- Rotational Range Adjustment : 45 to 320 degrees
- Selection Tools : Valve Selection Tool
- Take-back : No
- Temperature Ambient Operating Range : -40…136 °F (-40…57.7 °C)
- Temperature Shipping and Storage Range : -40…160 °F (-40…71 °C)
- Tightening Torque : 220 lb.in
- Tightening Torque : 25 N.m
