SRT3000RMXLT-5KTF

acoustic level :

55 dBA~~

Additional Information :

Configurable for 208 or 240 nominal output voltage

additional specification :

High density

Battery Charge Power (Watts) :

165 W rated

battery curve :

D

battery design life :

2 year(s)

Battery Life :

3…5 year(s)

battery option :

SRT96RMBP 1 1491 VAh

battery option :

SRT96RMBP 10 10437 VAh

battery option :

SRT96RMBP 2 2485 VAh

battery option :

SRT96RMBP 3 3479 VAh

battery option :

SRT96RMBP 4 4473 VAh

battery option :

SRT96RMBP 5 5467 VAh

battery option :

SRT96RMBP 6 6461 VAh

battery option :

SRT96RMBP 8 8449 VAh

Battery power in VAH :

497 VAh runtime

Battery Type :

Lead-Acid battery

Battery Voltage :

96V

Brand :

APC Brand

bypass type :

Internal Bypass (Automatic and Manual)

Cable Length :

10 ft (3.05 m)

California proposition 65 :

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Carbon footprint (kg CO2 eq, Total Life cycle) :

5643

Channel status :

Distribution

Color :

Black

Configurators/Selectors :

Computer rooms

Configurators/Selectors :

NetShelter

Configurators/Selectors :

PowerStruXure Type A

Configurators/Selectors :

UPS Selector

Configurators/Selectors :

UPS Selector Business Power

Configurators/Selectors :

Wiring closets

crest factor :

3 : 1

curve equation :

Efficiency

curve fixed loss :

0.0212

curve load maximum :

100 %

curve load minimum :

3 %

curve proportional loss :

0.022

curve square loss :

0.0242

curve X-axis maximum :

100 %

curve X-axis minimum :

0 %

curve X-axis title :

Load

curve X-axis units :

Percentage

curve Y-axis maximum :

100 %

curve Y-axis minimum :

50 %

curve Y-axis title :

Efficiency

curve Y-axis units :

Percentage

Depth :

25.00 in (63.5 cm)

Efficiency at full load :

100...275 V adjustable (half load)

Emergency Power Off (EPO) :

Yes

Extendable Run Time :

1

Final Result for Connectable :

Connectable with upgrade

Final Result for Flywheel performance tracking :

Connectable products

Form name :

UPS

free slots :

1

Global Keywords :

Smartup

Global Keywords :

Smartups

Global Keywords :

Ups

Global warming ; Total life cycle? :

5 643 kg CO2 eq.

graph display :

1

harmonic distortion :

Less than 2%

Heat Dissipation :

773 Btu/h

Height :

6.69 in (17 cm)

Included Battery Modules :

1

Input Connection Type :

NEMA L6-20P

Input Frequency :

40 - 70 Hz auto-sensing

IP Degree of Protection :

IP20

Kw Rating :

2700 W

Lead time :

Usually in Stock

Liquid Electrolyte Value :

0

Main Input Voltage :

208 V

Manufacturer :

American Power Conversion Corp. (APC)

Max Configurable Power (Watts) :

2700 W

Maximum configurable power in VA :

3000 VA

Mounting Location :

Front

Mounting Mode :

Rack-mounted

mounting position :

Horizontal

Mounting Preference :

Lower

Net Weight :

164.002 lb(US) (74.39 kg)

Number Of Cables :

1

Number of power module filled slots :

0

Number of power module free slots :

0

number of rack unit :

4U

Number of tare power :

53 W

OEM :

APC

Operating Altitude :

0...10000 ft

Optimized Energy Efficiency :

Energy efficient product

Other Input Voltages :

240 V

Other Output Voltages :

240 V

output connection type :

12 NEMA 5-20R

output connection type :

2 NEMA L6-20R

Output frequency :

50/60 Hz +/- 3 Hz sync to mains

Output Voltage :

120 V

Output Voltage :

208 V

Packaging made with recycled cardboard :

Yes

Packaging without single use plastic :

No

performance multiplier :

1

Prod Type :

UPS

Product Certifications :

ENERGY STAR V2.0 (USA)

Product Or Component Type :

Uninterruptible power supply (UPS)

Provided Equipment :

CD with software

Provided Equipment :

Documentation CD

Provided Equipment :

Installation guide

Provided Equipment :

Rack Mounting brackets

Provided Equipment :

Rack mounting hardware

Provided Equipment :

Rack Mounting support rails

Provided Equipment :

USB cable

Provided Equipment :

Warranty card

Rated Power In Va :

3000 VA

RBC Quantity :

1

redundant :

No

Relative Humidity :

0…95 % non-condensing

Removable battery :

User replaceable

SCIP Number :

A64c500c-f72a-458b-8faa-8175a94429fe

show note OP temperature :

No

size UPS version :

Internetworking

size UPS version :

Server

size UPS version :

Telecom

Storage Altitude :

0…50000 ft (0…15240 m)

Storage Relative Humidity :

0…95 % Non-condensing

Surge energy rating :

340 J

Take-back :

Yes

Temperature Ambient Operating Range :

32…104 °F (0…40 °C)

Temperature Shipping and Storage Range :

5…113 °F (-15…45 °C)

Topology :

Double Conversion Online

two post mountable :

0

Typical recharge time :

3 h

UNSPSC Classification v19 :

39121011

UNSPSC Classification v23 :

39121011

UPS design life :

7 year(s)

UPS size :

S

USB compatible :

Yes

value multiplier :

1

Warranty :

3 years repair or replace (excluding battery) and 2 years for battery

Waveform Type :

Sine wave

Width :

17.01 in (43.2 cm)

PDF :

https://iportal2.schneider-electric.com/Contents/docs/UPS-SRT3000RMXLT-5KTF_SPECIFICATION%20SHEET.PDF
