APC Smart-UPS Ultra On-Line, 3000VA, Lithium-ion, Rack/Tower 1U, 120V, 5x 5-20R + 1x L5-30R NEMA outlets, Network Card, Extended runtime, W/rail kit

acoustic level :

55 dB

After sales category ASC :

03 - Replace by the "same" Commercial Reference but Refurbished or Remanufactured

alarm :

Audible and visible alarms : prioritized by severity

Battery Charge Power (Watts) :

448 W

battery curve :

L1

battery option :

SRTL50RMBP1U-LI 1 1452 VAh

battery option :

SRTL50RMBP1U-LI 2 2592 VAh

battery option :

SRTL50RMBP1U-LI 3 3732 VAh

battery option :

SRTL50RMBP1U-LI 4 4872 VAh

battery option :

SRTL50RMBP1U-LI 5 6012 VAh

Battery power in VAH :

312 VAh runtime

Battery Type :

Li-Ion (Lithium Ion)

Battery Voltage :

50 V

Brand :

APC Brand

bypass type :

Internal Bypass (Automatic and Manual)

Cable Length :

8 ft (2.4 m)

Carbon footprint (kg CO2 eq, Total Life cycle) :

7237

Channel status :

Distribution

Color :

Silver grey

Configurators/Selectors :

Computer rooms

Configurators/Selectors :

NetShelter

Configurators/Selectors :

PowerStruXure Type A

Configurators/Selectors :

UPS Selector

Configurators/Selectors :

UPS Selector Business Power

Configurators/Selectors :

Wiring closets

Control panel :

Multi-function LCD status and control console

CR access level :

Non-Restricted - Does not require certified representative for installation

CR severity code :

06 - Product as a spare

CR shelf life :

24

crest factor :

3 : 1

curve equation :

Efficiency

curve fixed loss :

0.0216

curve load maximum :

100 %

curve load minimum :

3 %

curve proportional loss :

0.0110

curve square loss :

0.0432

curve test cond ID :

Curve fit to measured efficiency data. All measurements taken in normal operating mode, at typical environmental conditions, with nominal electrical input and balanced resistive load (PF = 1.0) output.

curve X-axis maximum :

100 %

curve X-axis minimum :

0 %

curve X-axis title :

Load

curve X-axis units :

Percentage

curve Y-axis maximum :

100 %

curve Y-axis minimum :

50 %

curve Y-axis title :

Efficiency

curve Y-axis units :

Percentage

Depth :

22.05 in (560 mm)

Emergency Power Off (EPO) :

Yes

Extendable Run Time :

1

Final Result for Connectable :

Connectable ready

Final Result for Flywheel performance tracking :

Connectable products

For Service Catalog Item :

Finished good

Form name :

UPS

Global Keywords :

3kVA sine wave UPS

Global Keywords :

APC Smart-UPS

Global Keywords :

Battery backup

Global Keywords :

Double conversion on-line UPS

Global Keywords :

EcoStruxure IT

Global Keywords :

Extendable runtime UPS

Global Keywords :

Lithium-ion UPS

Global Keywords :

Network monitoring SRTL UPS

Global Keywords :

Powerchute UPS software

Global Keywords :

Rack tower convertible UPS

Global Keywords :

Rackmount UPS

Global Keywords :

Schneider Electric Smart UPS

Global Keywords :

Uninterruptible power supply

Global Keywords :

Ups

Global warming ; Total life cycle? :

7 237 kg CO2 eq.

graph display :

1

Height :

1.7 in (43 mm)

Input Connection Type :

NEMA L5-30P

Input Frequency :

50/60 Hz

IP Degree of Protection :

IP20

Kw Rating :

2850 W

Lead time :

Usually in Stock

Liquid Electrolyte Value :

0

Main Input Voltage :

120 V

Main Input Voltage :

125 V

Manufacturer :

American Power Conversion Corp. (APC)

Max Configurable Power (Watts) :

2850 W

Maximum configurable power in VA :

2880 VA

Mounting Mode :

Rack-mounted with kit

Mounting Mode :

Tower-mounted with kit

Mounting Preference :

No preference

Net Weight :

35.05 lb(US) (15.9 kg)

Number Of Cables :

1

number of rack unit :

1U

Number of tare power :

49.5 W

OEM :

APC

Operating Altitude :

0...10000 ft

Order method :

ERP to ERP

Other Input Voltages :

120 V

Other Input Voltages :

125 V

Other Output Voltages :

120 V

Other Output Voltages :

125 V

output connection type :

1 NEMA L5-30R

output connection type :

5 NEMA 5-20R

Output frequency :

50/60 Hz +/- 3 Hz sync to mains

Output Voltage :

120 V

Packaging made with recycled cardboard :

Yes

Packaging without single use plastic :

No

performance multiplier :

1

Pre-Installed SmartSlotâ„¢ Cards :

Network management card with environmental monitoring

Preventive maintenance :

0

Prod Type :

UPS

Product Certifications :

FCC

Product Certifications :

UL/cUL listed

Product Or Component Type :

Uninterruptible power supply (UPS)

Provided Equipment :

Country-specific detachable power cord

Provided Equipment :

Installation guide

Provided Equipment :

Rack Mounting brackets

Provided Equipment :

Rack Mounting support rails

Provided Equipment :

RJ45 Cable

Provided Equipment :

USB cable

Provided Equipment :

Warranty card

Rated Power In Va :

2880 VA

RBC Quantity :

1

redundant :

No

Relative Humidity :

0…95 % non-condensing

Removable battery :

User replaceable

Return code :

01 - Return for Repair (RFR)

SCIP Number :

8c493f2b-82c6-495f-a54a-f7d594e2b537

show note OP temperature :

No

size UPS version :

Government/Education

size UPS version :

Internetworking

size UPS version :

Server

size UPS version :

Telecom

size UPS version :

Workstation

Spare Part Order Method direction :

Consult local ERP Setup

Spare used in spare kit :

No

Standards :

CSA C22.2 No.107.3-05

Standards :

FCC Part 15 class A

Standards :

UL 1778

Storage Altitude :

0…50000 ft (0…15240 m)

Storage Relative Humidity :

0…95 % Non-condensing

Take-back :

No

Temperature Ambient Operating Range :

32…104 °F (0…40 °C)

Temperature Shipping and Storage Range :

5…113 °F (-15…45 °C)

Topology :

On-Line

Toxic heavy metal free :

Yes

two post mountable :

1

Typical recharge time :

1.5 h

UNSPSC Classification v19 :

39121011

UNSPSC Classification v23 :

39121011

UPS size :

S

USB compatible :

Yes

value multiplier :

1

Warranty :

5 years repair or replace

Waveform Type :

Sine wave

Width :

17.008 in (432 mm)
