Current Switch:|Adjustable Trip Point|0.75 - 50 Amperage Range|Normally Open 1.0A@30VAC/DC|0.75A or less Minimum Trip Point|Split-Core Housing|Sensor Power Induced from monitored conductor|Insulation Class 600VAC RMS (UL), 300VAC RMS (CE)|Frequency Range 50/60 Hz|Temperature Range -15 deg. to 60 deg. C (5 deg. to 140 deg. F)|Humidity Range 10-90% RH, non-condensing|Hysteresis 10% (typical)|Terminal Block Maximum Wire Size 16 AWG|Terminal Block Torque (nominal) 7 in-lbs|Agency Approvals UL 508 open device listing CE: EN61010-1:2001-02, CAT III, deg. 2, basic insulation
- Application : Building Automation Systems~~
- AWG Gauge : AWG 24...AWG 14
- Brand : Veris Industries
- By Schneider : Yes
- Current Measurement Range : 00.75-50 A
- Final Result for Connectable : Connectable ready
- Final Result for Flywheel performance tracking : Connectable products
- Global Keywords : AC current
- Global Keywords : Belt loss
- Global Keywords : Building automation
- Global Keywords : Current Monitoring
- Global Keywords : Current Switch
- Global Keywords : Hawkeye
- Global Keywords : HVAC
- Global Keywords : Motor health sensor
- Global Keywords : Vfd
- Manufacturer : Schneider Electric
- Mounting Support : Split core housing
- Network Frequency : 50-60 Hz
- Opening Width : 0.3 in (8 mm)
- Output Current : 1 A at 30 V AC/DC
- Output Type : Switch Output
- Packaging made with recycled cardboard : No
- Packaging without single use plastic : No
- Product Certifications : CE
- Product Certifications : UL
- Product Or Component Type : Sensor
- Relative Humidity : 10…90 % RH, non-condensing
- Sensor Model : H308
- Sensor Type : Current switch, AC
- Setpoint : Yes
- Take-back : No
- Temperature Ambient Operating Range : 5…140 °F (-15…60 °C)
- Type Of Measurement : AC Current
