The Model 209 pressure transducer is designed for Industrial and OEM customers who require high performance, reliability and versatility at an affordable price. It offers exceptional ±0.25% FS accuracy with pressure ranges from 1 PSI up to 10,000 PSI to meet a multitude of demanding applications. The 209 features all stainless steel wetted materials and offers many pressure and electrical connections to satisfy challenging installation requirements. The 209 features a patented overpressure stop to protect the sensor against unexpected spikes or in high pulsation applications.True Low Range SensorThe Model 209’s capacitive transducer is designed for industrial applications with demanding price and performance requirements. The Model 209 offers exceptional reliability in typical industrial grade environments. The true low range sensor design offers high performance with no additional amplification required to meet range requirements down to 1 PSI.Flexibility for Many ApplicationsThe 209 transducer offers many pressure and electrical fittings covering many installation configurations. It minimizes additional engineering time to accommodate the sensor, allowing for earlier project completion and quicker time to market.Robust Design & Construction for Reliable ServiceThe Model 209 is designed and built to withstand demanding applications. The industrial construction, with optional positive overpressure stop, enables the sensor to withstand overpressure conditions up to 16X the rated range.
- Wetted material : NA
- Pressure range : NA
- Pressure Type : NA
- Pressure fitting : {2M} 1/4 NPT Male
- Output : {24} 0.5 to 5.5 VDC
- Elec. Termination : NA
- Accuracy : NA
- Option 1 : NA
- Option 2 : NA
- Shipping : 1 lbs.
- Range : {001P} 0 to 1 PSI
