EHO110

[Us] rated supply voltage :

15...36 V DC~~

[Us] rated supply voltage :

18...36 V DC

[Us] rated supply voltage :

21.6...26.4 V AC

Application :

Outdoor Reference

Brand :

Schneider Electric

By Schneider :

Yes

Color :

Cloud white

Device Short Name :

EHO

Distance Between Centers :

2.7 in (68 mm)

Drift Of The Sensitivity :

> 2 %

Feature Level :

Economy

Final Result for Connectable :

Connectable ready

Final Result for Flywheel performance tracking :

Connectable products

Function Available :

Field selectable output

Function Available :

Single point field calibration

Global Keywords :

Field selectable Output signals

Global Keywords :

Single point Field Calibration

Hysteresis :

0.4 %

Location :

Outdoor

Manufacturer :

Schneider Electric

Material :

ABS (acrylonitrile butadiene-styrene): housing

Maximum Power Consumption In Va :

1 VA

Measurement Accuracy :

0.1

Output Impedance :

10000 Ohm Continuum 25 °C

Output Impedance :

10000 Ohm I/A 25 °C

Output Impedance :

10000 Ohm I/Net 25 °C

Output Impedance :

1800 Ohm Vista 25 °C

Output Type :

Analog 2-wire 4...20 mA factory standard

Output Type :

Analog 3-wire 0...10 V DC

Output Type :

Analog 3-wire 0...5 V DC

Output Type :

Analog 3-wire DC 4...20 mA

Packaging made with recycled cardboard :

No

Packaging without single use plastic :

No

Product Compatibility :

Continuum

Product Compatibility :

I/A

Product Compatibility :

I/NET

Product Compatibility :

Vista

Product Or Component Type :

Sensor

Product Specific Application :

Building automation systems

Product Specific Application :

Humidity chambers

Product Specific Application :

OEM applications

Repeat Accuracy :

0.5

Selection Tools :

HVAC Sensors

Setpoint :

No

Standards :

NEMA 1

Take-back :

No

Temperature Ambient Operating Range :

-10…122 °F (-23.3…50 °C)

Temperature Shipping and Storage Range :

41…95 °F (5…35 °C)

Type Of Measurement :

Humidity

Warranty :

18 months

Width :

3.6 in (91 mm)

With Override :

No

PDF :

https://iportal2.schneider-electric.com/Contents/docs/EH%20SERIES_SPECIFICATION%20SHEET_F-28255-1.PDF
