- Accuracy Setting Knob : 5%
- Brand : Schneider Electric
- By Schneider : Yes
- Configuration : 2-Way
- Connection Type : NPT
- Control Signal : Proportional/Modulating
- Final Result for Connectable : Connectable ready
- Final Result for Flywheel performance tracking : Connectable products
- Flow Characteristic : Linear
- Flow Rate Maximum (l/s & l/h) : 0.3 l/s
- Flow Rate Maximum (m³/h) : 1.08 m³/h
- Flow Rate Maximum GPM : 4.75 gal(US)/min
- Flow Rate Minimum (l/s & l/h) : 0.05 l/s
- Flow Rate minimum GPM : 0.8 gal(US)/min
- Flow Rate Nominal (gpm) : 4 gal(US)/min
- Flow Rate Nominal (lps) : 0.25 l/s
- Flow Rate Nominal (m³/h) : 0.9 m³/h
- Force lbf : 21 lbf
- Force N : 90 N
- Global Keywords : Communicating actuator
- Global Keywords : PIBCV valve assembly
- Global Keywords : PIBCV with smart actuator
- Global Keywords : PICBCV communicating actuator
- Global Keywords : Smart actuator
- Global Keywords : SP90 valve assembly
- Indivisible Sale Qty : 1
- Insulation Class : Class III
- Loss of Power Type : Non-Spring Return
- Material Body : Brass
- Material Diaphragm : EPDM
- Mechanical Movement : Linear
- Media Compatibility : Glycol 25 %
- Motor Type : Brushless DC motor
- Override : Manual Override
- Packaging made with recycled cardboard : Yes
- Packaging without single use plastic : No
- Pipe Size : 3/4 in
- Pressure Allowable Static : 16 bar, 200 psi up to 150 °F
- Pressure Class : PN16
- Pressure Differential Maximum (kPa) : 600 kPa
- Pressure Differential Maximum PSI : 87 psi
- Pressure Differential Minimum (kPa) : 16 kPa
- Pressure Differential Minimum PSI : 2.32 psi
- Pressure Fluid Max Delta P Normal Life : 58 psi (399.9 kPa)
- Rangeability : 1000:1
- Seat Leakage : Class IV (0.01 %)
- Seat Material : EPDM
- Stem Movement : Linear
- Stroke Distance : 2.25 mm
- Take-back : No
- Temperature Range Fluid : 14…248 °F (-10…120 °C)
- Valve Product Range : SpaceLogic
- Valve Product Series : VP228E
- Valve Type : Electronic Pressure Independent~~
