Circuit breaker, PowerPacT J, unit mount, Micrologic 3.2, 250A, 3 pole, 18kA, 600VAC, undervoltage release
- [Ics] rated service breaking capacity : 18 kA 500/525 V AC 50/60 Hz IEC 60947-2~~
- [Ics] rated service breaking capacity : 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2
- [Ics] rated service breaking capacity : 65 kA 220/240 V AC 50/60 Hz IEC 60947-2
- [Ue] rated operational voltage : 600 V AC 50/60 Hz IEC 60947-3
- [Ui] rated insulation voltage : 750 V IEC 60947-2
- [Uimp] rated impulse withstand voltage : 8 kV IEC 60947-2
- Accessory / Separate Part Type : Voltage release 110...130 V AC compartment
- Application : Distribution
- AWG Gauge : AWG 3/0...350 kcmil aluminium/copper terminals
- Brand : Square D
- breaking capacity : 18 kA 600 V AC 50/60 Hz UL 489
- breaking capacity : 35 kA 480 V AC 50/60 Hz UL 489
- breaking capacity : 65 kA 240 V AC 50/60 Hz UL 489
- Breaking capacity code : G
- By Schneider : Yes
- Carbon footprint (kg CO2 eq, Total Life cycle) : 554
- circuit breaker application : HACR rated
- Communication Interface : Ethernet
- Communication Interface : Modbus
- continuous current rating : 80 %
- Depth : 3.4 in (86 mm)
- Electrical Connection : Lugs, line
- Electrical Connection : Lugs, load
- Final Result for Connectable : Connectable with upgrade
- Final Result for Flywheel performance tracking : Connectable products
- Global Keywords : 18 kA
- Global Keywords : 250 Amp
- Global Keywords : 250A
- Global Keywords : 3P
- Global Keywords : CB
- Global Keywords : Circuitbreaker
- Global Keywords : J-Frame
- Global Keywords : Lug
- Global Keywords : Lug connection
- Global Keywords : MCCB
- Global Keywords : Micrologic
- Global Keywords : Molded case
- Global Keywords : Powerpact j
- Global Keywords : Pp j
- Global Keywords : Three-pole
- Global warming ; Total life cycle? : 554 kg CO2 eq.
- Height : 7.5 in (191 mm)
- IP Degree of Protection : Front cover IP40
- Life cycle Comment : 20240308 request by Dante that moved to selector offering with typology ADP
- Line Rated Current : 250 A
- Local Signalling : Alarm 1 LED 105 % Ir red)
- Local Signalling : Alarm 1 LED 90 % Ir orange)
- Local Signalling : Ready 1 LED green)
- Local Signalling : Switched off (OFF) 1 trip indicator green)
- Long Time Pick-Up Adjustment Range : 0.25...1 x In
- Manufacturer : Square D
- Mounting Mode : Unit mount lug)
- Mounting Support : Lug
- Net Weight : 5.3 lb(US) (2.4 kg)
- Network Frequency : 50/60 Hz
- Number Of Slots : 1 alarm switch SD plug-in)
- Number Of Slots : 1 overcurrent trip switch SDE plug-in)
- Number Of Slots : 1 voltage release MN or MX plug-in)
- Number Of Slots : 2 auxiliary switch OF plug-in)
- Operating Altitude : 5000 m with derating
- Override : Toggle
- Packaging made with recycled cardboard : Yes
- Packaging without single use plastic : No
- Pollution Degree : 3 IEC 60947-1
- Product Certifications : CSA
- Product Certifications : NOM
- Product Certifications : UL
- Product Name : PowerPact J
- Product Or Component Type : Circuit breaker
- Protection Type : overload protection
- Protection Type : Short-circuit protection
- PVC free : Yes
- Quality Labels : CE
- Range : PowerPact
- Standards : CSA
- Standards : IEC 60947-2
- Standards : NEMA
- Standards : NOM-003-SCFI-2000
- Standards : UL
- suitability for isolation : Yes IEC 60947-2
- Take-back : No
- Temperature Ambient Operating Range : -13…158 °F (-25…70 °C)
- Temperature Shipping and Storage Range : -58…185 °F (-50…85 °C)
- Terminal Identifier : AL250JD
- Tightening Torque : 221.3 lbf.in (25 N.m) 0.1…0.3 in² (95…185 mm²) (AWG 3/0...350 kcmil)
- Trip Unit Name : Micrologic 3.2
- Trip Unit Technology : Electronic, standard, Micrologic 3.2, LI
- Type Of Network : 3P
- UNSPSC Classification v19 : 39121601
- UNSPSC Classification v23 : 39121601
- utilisation category : Category A
- Width : 4.09 in (104 mm)
- Wire Stripping Length : 1.0 in (25 mm)~~
