- Actuator Product Series : Serve Pro S70~~
- Actuator Type : Electric
- Additional Features : Heater
- Auxiliary Switch : 2 SPDT
- Body Size : 100 mm (4 in)
- Brand : Schneider Electric
- By Schneider : Yes
- Close-Off Pressure : 1966 kPa
- Close-Off Pressure : 285 psi
- Configuration : 2-Way
- Connection Type : Flanged
- Control Signal : 2-Position (On/Off)
- Disc Material : Stainless Steel 316
- Disc Shape : Full
- Final Result for Connectable : Not connectable
- Final Result for Flywheel performance tracking : Non Flywheel
- Flow Characteristic : Equal Percentage
- Flow Coefficient : 324.33 kvs
- Flow Coefficient : 375 cv
- IP Protection Rating : IP56
- Leads and Connections : Terminal Block
- Loss of Power Position : Fail in place
- Loss of Power Type : Non-Spring Return
- Material Body : Carbon steel
- Material Stem : 17-4 PH Stainless Steel
- Mechanical Movement : Rotary
- Media Compatibility : Glycol 25 %
- Media Compatibility : Glycol 30 %
- Media Compatibility : Glycol 50 %
- Media Compatibility : Glycol 60 %
- Media Compatibility : Water
- Override : Automatic reset
- Packaging made with recycled cardboard : Yes
- Packaging without single use plastic : No
- Pipe Size : 4 in
- Position Indicator : Green Push Stem with Color Markers
- Pressure Class : 150 ANSI
- Product Destination : butterfly valves
- Product Or Component Type : Valve-actuator assembly
- Rangeability : 33:1
- Seat Leakage : Port A: Class V
- Seat Material : Port A: Reinforced PTFE
- Seat Material : Port B: Reinforced PTFE
- Selection Tools : Valve Selection Tool
- Stem Movement : Rotary
- Take-back : No
- Temperature Ambient Operating Range : -40…150 °F (-40…65.5 °C)
- Valve Product Series : Full 6200 H1
- Valve Type : Butterfly
