Surge protection device, Surgelogic, HL, 120kA, 208Y/120 VAC, 3 phase, 4 wire, SPD type 2

[Uc] maximum continuous operating voltage :

150 V

[Ue] rated operational voltage :

208Y/120 V AC

Brand :

Square D

breaking capacity :

50 kA

Breaking capacity code :

HL

By Schneider :

Yes

Cable Length :

19.02 in (483 mm)

California proposition 65 :

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Connections - Terminals :

I-Line line

Connections - Terminals :

Lugs ground AWG 6 copper 35.4 lbf.in (4 N.m)

Connections - Terminals :

Lugs neutral AWG 6 copper 35.4 lbf.in (4 N.m)

Depth :

5.6 in (142.1 mm)

Device Short Name :

IMA

Final Result for Connectable :

Not connectable

Final Result for Flywheel performance tracking :

Non Flywheel

Global Keywords :

protection

Global Keywords :

120kA

Global Keywords :

HL

Global Keywords :

SPD type 2

Global Keywords :

Surge

Global Keywords :

Surgelogic

Height :

12.2 in (308.9 mm)

Line Rated Current :

60 A

Local Signalling :

Status LED green per phase normal operation

Local Signalling :

Status LED red per phase fault

Manufacturer :

Schneider Electric

Mounting Support :

Panel mounting

NEMA Protection Rating :

NEMA 2

number of poles :

3

Packaging made with recycled cardboard :

No

Packaging without single use plastic :

No

Phase :

3 phase

Product Or Component Type :

Surge protection device

Provided Equipment :

Alarm enable/disable switch

Provided Equipment :

Circuit-breaker

Provided Equipment :

Surge counter

short-circuit protection :

200 kA

Standards :

CSA C22.2 No 5-09

Standards :

CSA C22.2 No 8:1986

Standards :

UL 1283:ed. 5

Standards :

UL 1449:ed. 3

Standards :

UL 489:ed. 11

Standards :

UL 96A:ed. 12

surge current :

120 kA

Take-back :

No

Trip Unit Technology :

Thermal-magnetic

UNSPSC Classification v19 :

39121112

UNSPSC Classification v23 :

39121112

Width :

13.5 in (341.9 mm)

wiring configuration :

4-wire
