Schneider Electric

[Icm] rated short-circuit making capacity :

1 kA 400 V at Ipeak~~

[Icw] rated short-time withstand current :

300 A 400 V 1 s

[Ie] rated operational current :

8.1 A AC-23 Ue: 400 V

[Ith] conventional free air thermal current :

12 A

[Ithe] conventional enclosed thermal current :

10 A

[Ue] rated operational voltage :

690 V AC 50/60 Hz

[Uimp] rated impulse withstand voltage :

8 kV

Brand :

Schneider Electric

breaking capacity :

120 A 400 V AC-21A)

breaking capacity :

120 A 400 V AC-22A)

breaking capacity :

120 A 400 V AC-23A)

By Schneider :

Yes

Carbon footprint (kg CO2 eq, Total Life cycle) :

47

Circularity Profile :

No need of specific recycling operations

Connections - Terminals :

Power circuit screw clamp terminals 0.009 inÂ² (6 mmÂ²) flexible - with cable end

Connections - Terminals :

Power circuit screw clamp terminals 0.02 inÂ² (10 mmÂ²) solid

Contacts Type And Composition :

3 NO

Depth :

2.4 in (60 mm)

Device Short Name :

V

Electrical Durability :

100000 cycles AC-21

Electrical Durability :

30000 cycles DC-1

Electrical Durability :

30000 cycles DC-2

Electrical Durability :

30000 cycles DC-3

Electrical Durability :

30000 cycles DC-4

Electrical Durability :

30000 cycles DC-5

Final Result for Flywheel performance tracking :

Non Flywheel

fire resistance :

1760 Â°F (960 Â°C) IEC 60695-2-1

Global Keywords :

Load switch body

Global warming ; Total life cycle? :

47 kg CO2 eq.

Halogen content performance :

Halogen free product

Height :

2.9 in (74 mm)

intermittent duty class :

30

IP Degree of Protection :

IP20 conforming to IEC 60529

making capacity :

120 A 400 V AC-21A

making capacity :

120 A 400 V AC-22A

making capacity :

120 A 400 V AC-23A

Manufacturer :

Schneider Electric

Mechanical Durability :

100000 cycles

Mechanical Robustness :

Shocks 11 ms 30 Gn) IEC 60068-2-27

Mechanical Robustness :

Vibrations 10...150 Hz 1 gn) IEC 60068-2-6

Mounting Support :

Plate

Mounting Support :

Symmetrical rail

Net Weight :

0.4 lb(US) (0.2 kg)

Network Frequency :

50/60 Hz

Network Type :

AC

Network Type :

DC

Number of Units in Package 2 :

24

Number of Units in Package 3 :

192

Package 2 GTIN :

43389110448847

Package 2 Height :

11.81 in (30.000 cm)

Package 2 Length :

15.75 in (40.000 cm)

Package 2 Weight :

10.322 lb(US) (4.682 kg)

Package 2 width :

11.81 in (30.000 cm)

Package 3 Height :

29.53 in (75.000 cm)

Package 3 Length :

31.50 in (80.000 cm)

Package 3 Weight :

103.697 lb(US) (47.036 kg)

Package 3 width :

23.62 in (60.000 cm)

Packaging made with recycled cardboard :

Yes

Packaging without single use plastic :

Yes

performance level :

High performance

Product Certifications :

CCC

Product Certifications :

CSA

Product Certifications :

GL

Product Certifications :

UKCA

Product Certifications :

UL

Product Name :

TeSys VARIO

Product Or Component Type :

Switch body

Protective Treatment :

TC

PVC free :

Yes

Range :

TeSys

rated conditional short-circuit current :

10 kA 400 V 12 A aM

rated conditional short-circuit current :

10 kA 400 V 12 A gG
