Valve Assembly: |Body Size: 1/2 in |Configuration: 2-Way |Type: Globe |Body Pattern: Straightway |Connection: NPT |Stem Flow Action: Stem up A open |Material Trim: Brass |Flow Coefficient: 2.2 cv |Close-Off Pressure: 90 PSI |Actuator Type: Pneumatic |Control Signal: 2-Position (On/Off), Proportional |Control Spring Range: 3 to 7 PSIG, 5 to 10 PSIG, 8 to 13 PSIG |Loss of Power Type: Spring Return |Loss of Power Position: Normally open |Leads and Connections: 1/8 in Air NPT |Mechanical Movement: Linear |Protection Rating: NEMA 1 Assembly Components:|Valve Body: VB-7213-0-4-03 |Valve Range: Venta |Valve Linkage: AV-7400 |Actuator: MK-2690 |Actuator Comment: Comes with a blue 8 to 13 PSIG spring
- ProductOrComponentType : Valve-actuatorassembly
- Rangeability : 100:1
- SeatLeakage : PortA:ClassIV(0.01%), PortA:ClassV
- SeatMaterial : PortA:bronze
- SeatingSealMaterial : PTFE
- StemFlowAction : StemUpAOpened
- StemMovement : Linear
- StrokeAutoCalibration : No
- StrokeDistance : 7/16in
- TemperatureAmbientOperatingRange : -20\xe2\x80\xa6220\xc2\xb0F(-28.8\xe2\x80\xa6104.4\xc2\xb0C)
- TemperatureRangeFluid : 19\xe2\x80\xa6280\xc2\xb0F(-7\xe2\x80\xa6138\xc2\xb0C)
- TemperatureRangeSaturatedSteam : 19\xe2\x80\xa6280\xc2\xb0F(-7\xe2\x80\xa6138\xc2\xb0C)
- TemperatureShippingandStorageRange : -40\xe2\x80\xa6220\xc2\xb0F(-40\xe2\x80\xa6104.4\xc2\xb0C)
- ValveProductRange : Venta
- ValveProductSeries : VB-7200
- ValveType : Globe
- Actuator Comment : Comes with a blue 8 to 13 PSIG spring~~
- Actuator Product Series : MK-2690
- Actuator Type : Pneumatic
- Body Pattern : Straightway
- Body Size : 15 mm (1/2 in)
- Brand : Schneider Electric
- By Schneider : Yes
- Circularity Profile : No need of specific recycling operations
- Close-Off Pressure : 621 kPa
- Close-Off Pressure : 90 psi
- Configuration : 2-Way
- Connection Type : NPT
- Control Signal : 2-Position (On/Off)
- Control Signal : Proportional/Modulating
- Diaphragm Effective Area : 6 in² (38.7 cm²)
- Final Result for Connectable : Not connectable
- Final Result for Flywheel performance tracking : Non Flywheel
- Flow Characteristic : Equal Percentage
- Flow Coefficient : 1.9 kvs
- Flow Coefficient : 2.2 cv
- Humidity : 5-95 % non-condensing
- IP Protection Rating : IP10
- Lead Length : 1/8 in
- Leads and Connections : Air NPT
- Loss of Power Position : Normally open
- Loss of Power Type : Spring return
- Manufacturer : Schneider Electric
- Material : Die cast aluminium: housing
- Material Body : Bronze
- Material Diaphragm : Neoprene
- Material Plug : Brass
- Material Trim : Brass
- Mechanical Movement : Linear
- Media Compatibility : Glycol 25 %
- Media Compatibility : Glycol 30 %
- Media Compatibility : Glycol 50 %
- Media Compatibility : Glycol 60 %
- Media Compatibility : Steam
- Media Compatibility : Water
- Override : Manual override with 5/32 allen wrench
- Packaging made with recycled cardboard : Yes
- Packaging without single use plastic : No
- Packing Material : Spring-Loaded PTFE/EPDM
- Pipe Size : 1/2 in
- Position Indicator : Green Push Stem with Color Markers
- Positioner : No
- Pressure Allowable Static : 400 psig up to 150 °F decreasing to 321 psig at 281 °F
- Pressure Class : 250 ANSI
- Pressure Fluid Max Delta P Normal Life : 87 psi (599.8 kPa)
- Pressure Fluid Max Delta P Quiet Service : 35 psi (241.3 kPa)
- Pressure Saturated Steam Maximum Inlet : 241.3 kPa
- Pressure Saturated Steam Maximum Inlet : 35 psi
- Product Destination : globe valve
- Product Or Component Type : Valve-actuator assembly
- Seat Leakage : Port A: Class IV (0.01 %)
- Seat Leakage : Port A: Class V
- Seat Material : Port A: bronze
- Seating Seal Material : PTFE
- Selection Tools : Valve Selection Tool
- Stem Flow Action : Stem Up A Opened
- Stem Movement : Linear
- Stroke Auto Calibration : No
- Stroke Distance : 7/16 in
- Take-back : No
- Temperature Ambient Operating Range : -20-220 °F (-28.8-104.4 °C)
- Temperature Range Fluid : 19-280 °F (-7-138 °C)
- Temperature Range Saturated Steam : 19-280 °F (-7-138 °C)
- Temperature Shipping and Storage Range : -40-220 °F (-40-104.4 °C)
- Valve Product Range : Venta
- Valve Product Series : VB-7200
- Valve Type : Globe
