SMC1000-2UC

acoustic level :

41 dBA

additional specification :

Cloud-enabled monitoring

After sales category ASC :

03 - Replace by the "same" Commercial Reference but Refurbished or Remanufactured

alarm :

Alarm when on battery : distinctive low battery alarm : configurable delays

Battery Charge Power (Watts) :

72 W rated

battery curve :

A

Battery Life :

4…6 year(s)

Battery power in VAH :

211 VAh runtime

Battery Slots Empty :

0

Battery Type :

Lead-Acid battery

Brand :

APC Brand

Cable Length :

8 ft (2.4 m)

California proposition 65 :

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Carbon footprint (kg CO2 eq, Total Life cycle) :

923

Channel status :

Distribution

Color :

Black

Communication Port Support :

SmartConnect Ethernet port: for cloud monitoring feature availability varies by terms of use

communication port type :

SmartConnect Ethernet port

Configurators/Selectors :

Computer rooms

Configurators/Selectors :

NetShelter

Configurators/Selectors :

PowerStruXure Type A

Configurators/Selectors :

UPS Selector

Configurators/Selectors :

UPS Selector Business Power

Configurators/Selectors :

Wiring closets

Control panel :

Multi-function LCD status and control console

CR access level :

Non-Restricted - Does not require certified representative for installation

CR severity code :

06 - Product as a spare

CR shelf life :

12

curve equation :

Efficiency

curve fixed loss :

0.0058

curve load maximum :

100 %

curve load minimum :

1 %

curve proportional loss :

0

curve square loss :

0.0049

curve X-axis maximum :

100 %

curve X-axis minimum :

0 %

curve X-axis title :

Load

curve X-axis units :

Percentage

curve Y-axis maximum :

100 %

curve Y-axis minimum :

50 %

curve Y-axis title :

Efficiency

curve Y-axis units :

Percentage

Depth :

15.98 in (40.6 cm)

Efficiency at full load :

85...136 V adjustable

Efficiency at full load :

93...130 V

Equipment protection policy :

Lifetime : $150000

Extendable Run Time :

0

Filtering :

Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : m

Final Result for Connectable :

Connectable ready

Final Result for Flywheel performance tracking :

Connectable products

For Service Catalog Item :

Finished good

Form name :

UPS

free slots :

0

Global Keywords :

120V input UPS

Global Keywords :

1kVA sine wave UPS

Global Keywords :

2U Rackmount UPS

Global Keywords :

APC Smart-UPS C

Global Keywords :

Automatic Voltage Regulation UPS

Global Keywords :

AVR UPS

Global Keywords :

Battery backup

Global Keywords :

Cloud monitoring ups

Global Keywords :

EcoStruxure IT

Global Keywords :

Ethernet port UPS

Global Keywords :

LCD display UPS

Global Keywords :

Schneider Electric line interactive Smart UPS

Global Keywords :

Smart connect SMC UPS

Global Keywords :

Uninterruptible power supply

Global Keywords :

Ups

Global warming ; Total life cycle? :

923 kg CO2 eq.

graph display :

1

harmonic distortion :

Less than 5%

Heat Dissipation :

175 Btu/h

Height :

3.39 in (8.6 cm)

Included Battery Modules :

0

Input Connection Type :

NEMA 5-15P

Input Frequency :

50/60 Hz +/- 3 Hz auto-sensing

Kw Rating :

600 W

Lead time :

Usually Ships within 2 Weeks

Liquid Electrolyte Value :

0

Main Input Voltage :

120 V

Manufacturer :

American Power Conversion Corp. (APC)

Max Configurable Power (Watts) :

600 W

Maximum configurable power in VA :

1000 VA

Mounting Location :

Front

Mounting Mode :

Rack-mounted

Mounting Preference :

Lower

Net Weight :

45.24 lb(US) (20.52 kg)

Number Of Cables :

1

Number of power module :

0

Number of power module filled slots :

0

Number of power module free slots :

0

number of rack unit :

2U

Number of tare power :

37.81 W

OEM :

APC

Operating Altitude :

0...10000 ft

Optimized Energy Efficiency :

Energy efficient product

Order method :

ERP to ERP

Other Input Voltages :

110 V

Other Input Voltages :

125 V

Other Output Voltages :

110 V

Other Output Voltages :

125 V

output connection type :

6 NEMA 5-15R

Output frequency :

50/60 Hz +/- 3 Hz sync to mains

Output Voltage :

120 V

Packaging made with recycled cardboard :

Yes

Packaging without single use plastic :

No

performance multiplier :

1

Preventive maintenance :

0

Prod Type :

UPS

Product Certifications :

CULus

Product Certifications :

ENERGY STAR V2.0 (USA)

Product Or Component Type :

Uninterruptible power supply (UPS)

Provided Equipment :

Documentation CD

Provided Equipment :

Installation guide

Provided Equipment :

Rack Mounting brackets

Provided Equipment :

USB cable

Rated Power In Va :

1000 VA

RBC Quantity :

1

redundant :

No

Relative Humidity :

0…95 %

Removable battery :

User replaceable

Return code :

01 - Return for Repair (RFR)

SCIP Number :

B2b22a56-41f2-497e-9ea6-cf093b3b8bd3

show note OP temperature :

No

size UPS version :

Internetworking

size UPS version :

Server

size UPS version :

Telecom

Software Package :

SmartConnect software for remote power monitoring feature availability varies by terms of use

Spare Part Order Method direction :

Consult local ERP Setup

Spare used in spare kit :

No

Storage Altitude :

0…50000 ft (0…15240 m)

Storage Relative Humidity :

0…95 %

Surge energy rating :

680 J

Take-back :

Yes

Temperature Ambient Operating Range :

32…104 °F (0…40 °C)

Temperature Shipping and Storage Range :

5…113 °F (-15…45 °C)

Topology :

Line Interactive

Transfer Time :

6ms typical : 10ms maximum

two post mountable :

0

Typical recharge time :

3 h

UNSPSC Classification v19 :

39121011

UNSPSC Classification v23 :

39121011

UPS size :

S

USB compatible :

Yes

value multiplier :

1

Warranty :

2 years repair or replace

Waveform Type :

Sine wave

Width :

17.01 in (43.2 cm)

PDF :

https://iportal2.schneider-electric.com/Contents/docs/SMC1000-2UC_DATA%20SHEET.PDF
